Product code: 9509707
Fixing Point Distance | 525 mm |
---|---|
Pan Height to Top of Seat | 465 mm |
Projection | 805 mm |
S Trap Max Setout | 290 mm |
S Trap Min Setout | 190 mm |
Weight of Seat | 1.1 kg |
Weight of Pan | 50 kg |
Width | 360 mm |
Toilet Seat | Single Flap Seat |
---|
Pan Colour | White |
---|---|
Toilet Seat Colour | Grey |
Cistern Material | Plastic |
---|---|
Pan Material | Vitreous China |
Toilet Seat Material | Urea with Stainless steel hinges |
Cistern Installation | Inwall |
---|---|
Cistern Operation | Pneumatic |
Standards | AS 1428 .1 |
Water Inlet Position | Back Inlet |
Cistern Max Operating Pressure | 1000 kPa |
---|---|
Cistern Recommended Operating Pressure | 300-500kPa |
Average Litres Per Flush | 3.5 ltr |
---|---|
Full Flush | 4.5 ltr |
Half Flush | 3 ltr |
Star Rating | 4 Star |
Rating | 4 Star Rating |
---|---|
Measure | 4.5 Litres Per Full Flush |
Measure | 3.0 Litres Per Half Flush |
Measure | 3.5 Average Flush P/Ltr |
Toilet Seat Replacement Only | 12 Months |
---|---|
Warranty - Domestic Use | 5 Years |
Spare Parts and Labour | 12 Months |
Warranty - Commercial Use | 5 Years |
Warranty Information | For full warranty terms and conditions please refer to the Wolfen Warranty document. For Hideaway+ Cistern Warranty refer Hideaway+ Warranty. |
