EVO-AQUA 2HP MHBP 1PH FH4524ZHR-HE-XC suitable for R404A/R448A/R452A/R449A

Product code: 3507134

View Product Specifications

Tecumseh Evo-Aqua

This range of Tecumseh semi-hermetic condensing units is fully fitted and wired to make installation fast and efficient. EVO Semi has been designed to operate efficiently in both the hot and cold extremes of the Australian environment. The range is designed for R134a, R404A, R407F and R507 and can be applied in both low and medium temperature applications.

Features	* Tecumseh Hermetic compressor * Noise advantage compared to air-cooled condensing units * Consistent operating conditions provided by constant condensing water temperatures * HP/LP control * Brazed plate condenser * Circuit breakers * Compressor contactor * Compressor thermal overload * Liquid line filter drier * Liquid line sight glass * Liquid receiver * Oil separator * Crankcase heater and oil sight glass on all FH, TFH and TAG models * Suction accumulator on low temperature models
Refrigerant Type	R448A, R404A & R452A
Model Number	FH4524ZHR-HE-XC
Compressor Model	FH4524Z-XC
Length	600 mm
Width	600 mm
Height	604 mm
Suction Connection Size	5/8 "
Liquid Connection Size	3/8 "
Weight	62 kg
Receiver Capacity at 80%	3.9 kg
Nominal Horsepower	2 HP
Sound Power Level	73 dBA
Compressor MOC	12.4 A
Compressor Electrical Supply	240 V
Compressor Phase	Single Phase
